AMERIGO

Recent Upgrades

2020

Northern light generator ML673.

Cockpit cushions.

2021

North Dacron mainsail with 3 reefs.

2022

Teak deck replaced with 13mm Burmese teak.

New deck hatch lenses.

Dodgers replaced.

2023

New Yanmar 4JH 110hp with approximately 1600hrs as of March 2026.

New prop shaft.

Rudder removed and bearings checked and replaced.

Italian leather white upholstery and protective delivery covers.

New curtains

Starlink tower and unit.

New Fusion music system and speakers.

Roller furling line.

Main fridge/freezer new cooling plates and replaced with DC cooling compressors air cooled.

Small Isotherm drinks fridge with teak laminate cover.

2024

Replaced external fuel filters.

2 new Racor filter system.

Both pumps replaced on Spectra water maker.

Lewmar windlass motor replaced.

New anchor chain.

Starter, buffer, generator.

New halyard.

Jib sheets.

Jib halyard.

2025

Fuel valves fully serviced, and fittings replaced.

New motor on main halyard electric winch.

New genset mixing elbow.

New Lifeline house batteries.

All electronics replaced with new B&G including;

3 x mast displays.

Extended carbon anemometer.

1 x forward cabin display, 1 x master cabin display, 2 x multi display aft cockpit and 2 wind displays.

2 x Zeus chart plotters, 1 x at nav station and 1 x at helm.

Radar.

Autopilot.

Ram serviced.

New autopilot motor/pump.

VHF base set and remote VHF by helm.

Life raft serviced.

2026

New main auto/manual bilge pump.

New jib on order should arrive April 2026.

HULL

Solid fiberglass, white gel coat hull.

Solid fiberglass, white gelcoat hull.

Black sheer and waterline stripes.

Bottom antifoul painted (2017).

Fin keel with bulb, 9'3" draft.

Spade rudder. (rudder bearing, upper and lower, new 2023).

Hydraulic, drop-down transom, to form a swim platform.

DECK

Cored fiberglass deck with teak overlay.

Teak overlay new with 13mm teak (2022).

Teak toe rail.

Stainless-steel stem head fitting with double rollers.

Lewmar V4, 24volt recessed anchor windlass with gypsy and capstan (2018).

Windlass motor replaced (2024)

Windlass remote with chain counter (2018).

27kg CQR anchor.

Collapsible Fortress anchor in a bag.

275ft x 10mm G4 anchor chain (2024).

Stainless-steel chain guard on deck.

Pedestal steering.

70" stainless-steel steering wheel.

Carbon fiber, clear-coated radar post aft with antennas and transom light.

Additional and optional deck hatches for increased ventilation and light.

Floating genoa cars with control lines.

Under deck running rigging for some lines.

Dodgers for mid and aft cockpits.

WINCHES

All Lewmar.

Carbon, clear coated pedestal in mid cockpit to power primary winches.

2 x #77, 3 speed, electric, self tail, primary.

2 x #58, 2 speed, self tail, secondary.

1 x #64, 2 speed, electric, self tail, mainsheet.

1 x #50, 2 speed, self tail, traveler.

2 x #58, 2 speed, self tail, halyard.

1 x #54, 2 speed, electric, self tail, halyard and utility.

1 x #54, 2 speed, self tail, halyard and utility.

 Accommodations

General Arrangement

Sleeps 6 in 3 separate sleeping cabins plus 1 in the fore peak cabin and 2 more in the main saloon for a total of 9. The interior is varnished, hand rubbed, Burmese teak except as noted otherwise with teak and holly cabin sole. The overheads are vinyl.

Fore peak

Single bunk to starboard with ample storage under. Stainless-steel work top and lockers to port. There are steps up to access the main hatch on the fore deck.

forward head

Located immediately aft of the fore peak cabin and on the starboard side. Access from the starboard and port guest cabins as well as the fore peak cabin. White gel coated fiberglass unit with electric head, sink, pressure hot and cold water, exhaust fan and lockers.

forward guest cabins

Port and starboard cabins, starboard slightly larger, each with 2 single bunks, one above the other. Drawer under lower bunk and lockers outboard. Hanging locker in the starboard cabin.

Main saloon

Located aft of the guest cabins. Handrails in headliner. "L" shaped dinette with settee to starboard with 2 single chairs inboard and a removable stool aft. Wine bottle storage in dining table. Lockers and shelves outboard. Glass door glasses cabinet on forward bulkhead. Straight settee to port with lockers and entertainment center outboard. White Italian leather upholstery, new 2023.

navigation station

Located aft of the saloon on the starboard side facing forward. Double seat. Drawers. Surrounded by navigation and communication electronics and inboard the AC and DC electrical panel. Companionway stairs to the mid cockpit is located between the navigation station and the galley. The stairs lift for easy access to the engine and generator space.

galley

Located on the port side and in the walkway to the aft master cabin. Top load Iceberg freezer with 3 baskets and side load fridge forward driven by engine or 115volt, 50/60Hz. 3 burner stove with oven next aft. Microwave oven. Lockers and drawers under the Corian counter and outboard. Wet locker aft. Double stainless-steel sinks inboard and under the mid cockpit. Lockers above. Door aft to access the aft end of the engine and generator space.

master cabin

Located in the stern with centerline queen bed. Lockers, drawers and counter tops surround the bed. GRP lined wet locker with drain to the bilge. Vanity to starboard. There is also a ladder at the foot of the bed up to the forward end of the aft cockpit. New mattresses throughout the yacht, 2013.

master cabin head

Larger than standard. Located forward and to starboard of the master cabin. Gel coated fiberglass unit with sink and electric head.

Engine and Mechanics

New Yanmar 4JH 110hp (2023) with approx 1600hrs as of March 2026.

Propeller shaft (2023)

Water pump new (2017)

156 gallons diesel in 3 stainless-steel tanks.

2 x Racor fuel/water separators.

750nm range under engine at 7.7 knots and 2500rpm.

Engine mounts replaced (2013).

Engine exhaust grills powder coated (2014).

Reverso oil change pump 24volt for generator and main engine.

Plumbing and Ventilation

PLUMBING

Spectra Cape Horn water maker 16gph, (2014) with new filters (2016) new membrane (2018) Clark pump serviced.

Hot water tank (2013).

Electric automatic bilge pump with manual override (2019).

2 x manual bilge pumps.

207 gallons of water in 4 stainless-steel tanks.

Stainless-steel, 15 gallon, black water holding tank for each of the 2 heads.

Fresh water and sea water foot pumps in galley.

Hot and cold water deck shower.

Electric shower sump pump to grey water tank.

Electric heads with macerators.

VENTILATION

Stainless-steel dorade vents, powder coated 2017.

Hella fans throughout the interior.

Espar Hydronic 45 heating system, serviced (2018), with new fans (2018).

Wired for future installation of air-conditioning system.

Electrical

Northern Lights genset 2020.

Generator exhaust elbow (new April 2019).

Large alternator on main engine, 24volt.

Alternator on main engine for starter battery, 12volt.

New generator water, fuel and injector pumps and hoses 2013.

Generator heat exchanger new (2018).

New generator exhaust elbow and hose (2019).

New shore power cord, 2018.

Shore power deck plugs, 230volt and 115volt, including transformer.

115volt provided throughout the interior.

Battery charger/inverter.

House battery bank, 24volt, 4 x Lifeline GPL-8D AGM with 510Ah (new 2025).

Electronics buffer battery, 12volt (July 2016).

Generator start battery, 12volt, new (2016).

Main engine start battery, 12volt, new (2016).

12volt converter for electronics, 2013.

Cable TV/phone deck inlet.

Chrome reading lights with LED bulbs.

Deck light switch in master cabin.

LED overhead lights.

Navigation Electronics

Thinkpad T530 laptop (new Sept 2019) + backup computer.

B&G instruments (2025).

3 x displays on carbon bracket on mast.

2 x 20/20 displays in cockpit.

3 x MFDs, 1 at navigation station, 1 in the master cabin and 1 in the port guest cabin.

1 x wind and magnified wind displays.

VHF in cockpit linked to navigation station.

VHF with DSC at chart table.

Zeus screen at helm.

Zeus screen at navigation station.

AIS.

Nobeltec, Time Zero Navigator 3.0, with numerous charts (2018).

ICOM IC M170 SSB with grounding cage and insulated backstay.

Iridium satcom, handheld with docking station.

B&G autopilot using a hydraulic ram.

Barograph and barometer.

Western digital media player with 1Tb of media.

Rigging

Intermediate modulus, carbon fiber mast with 3 spreaders.

Mast and boom serviced and painted (2016).

Stainless-steel Navtec rod rigging (new 2016).

Forestay, backstay and checkstays (new 2016).

Main halyard new (2016)

2 x pair foot steps.

Trisail track.

Stainless-steel shroud covers.

T300 carbon Park Ave boom.

Navtec system 50 control panel with 2 speed pump (serviced 2019).

Hydraulics for mainsail outhaul, backstay and boomvang.

Aluminum bow sprit.

Carbon spinnaker pole.

Running rigging replaced as necessary.

Reckmann, RS 2000/40 roller furling for headsail.

SAILS

Mainsail, North, Dacron, full batten (2021).

North jib (to be delivered April 2026).

North, genoa (2020)

North, 120% genoa, 295TX Gatorback (2012).

Main and jib fully serviced 2018.

Asymmetrical gennaker with sock.

Storm trysail.

Storm jib.

Additional Equipment

27kg CQR stainless steel anchor.

60lb CQR galvanized spare anchor with chain and rode.

265ft, 3/8, G4 HT galvanized anchor chain (new Oct 2019).

Coolmatic RA-40M, 40 liter drinks fridge.

Splendid 2000, washer/dryer 115volt, 60Hz vented in galley (new 2018).

Stereo volume control in cockpit.

TV/PC monitor port side main saloon (2013).

JVC stereo with LCD, multiple amplifiers and speakers for surround sound.

Waterproof cockpit speakers.

Lee cloths.

Cockpit table.

Cockpit cushions (2012).

Fore deck awning.

Main deck awning with side panels.

Offshore covers for companionway and floorboards.

Highfield Classic 340, 11'6" dinghy (2019) with oars and manual bilge pump.

Yamaha 15HP Enduro outboard engine (2017).

Out board engine bracket on stern rail.

2 x horseshoe life rings.

6 person Plastimo life raft (2017) in a valise.

ACR ditch bag. 2 x Garmin portable GPSs.

2 x waterproof handheld VHFs. Spotlight.

6 x offshore PFDs with replacement CO2 cartridges.

6 x harnesses.

2 x 60ft jacklines.

10 x PFDs (3 for children, I for infant).

Full set of spare parts and tools for all major systems.

Security bars for fwd and aft hatches.

Lockable floorboards.

Paper charts from Western Europe to Western Africa to Caribbean to East Coast USA.

Bedding, monogrammed towels, pillows (new Sept 2019).

Disclaimer

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
