JUICE

Hull

Solid fiberglass hull painted flag blue (2017) with white stripes

Hull bottom board sanded to improve race performance

Hull bottom painted (Nov 2020)

Sugar scoop transom

Fin keel with bulb

Spade rudder

Viewing port for propeller

Deck

Cored fiberglass deck with teak overlay

Stainless steel stem head fitting with double anchor roller

Lewmar CPX electric windlass

Anodized aluminum toe rail

Stainless steel bow and stern rails

Stainless steel stanchions with 1 x 19 double stainless steel wire lifelines

Lifeline gates port and starboard

Gate in stern rail to access the swim platform

Staysail tracks with car on edge of coachroof

Genoa tracks with 2 cars on each located on side decks

Car pullers on genoa tracks

8 x Wichard "D" hooks for outboard headsail sheeting and other

Custom mainsheet system allowing the mainsheet to be trimmed from the helm station

Line stoppers on the mainsheet allowing the mainsheet winches to be freed up for additional purposes (check stay and secondaries)

Mainsheet traveler track located immediately forward of the pedestal

Pedestal steering

Stainless steel wheel with elkhide cover

Custom stainless steel pedestal guard allowing protection of helm naivgation hardware

Spinlock line clutches either side of the companionway (2015) as well as other locations on deck

Cross over sheeves aft of clutches allowing the port or starboard winch to be used

Radar post aft with radar dome, antennas and outboard engine davit

Winches

All Harken anodized self tailing

2 x #64, 3 speed, electric primary

2 x #53, 2 speed, electric mainsheet

1 x #48, 2 speed, electric halyard

1 x #48, 2 speed, halyard

Halyard winches are also used as secondaries

General Arrangement

Accomodations

Sleeps 4, 2 in each of the 2 sleeping cabins, plus 1 on each settee and 1 in the port pilot berth over the port settee for a total of 7. Varnished, hand rubbed, Burmese teak interior furniture with teak and holly cabin sole. Vinyl overhead panels.

Forward cabin

"V" berth with filler to make a double. Storage and space for water maker and air-conditioning unit under the bunk. Shelves port and starboard. Hanging locker aft to starboard.

Forward head

Located on the port side aft of the forward cabin. White gel coated fiberglass unit to half height. Teak cabinetry above with lockers outboard. Manual salt water head with its own holding tank. Mirror forward. Sink with hot and cold pressure water and telephone type shower.

Main Saloon

"L" shaped settee to port surrounding the dining table with folding leaves either side. House batteries stored in dining table base with vent to the mast. Pilot berth outboard. Straight settee to starboard with lockers and shelving outboard. Storage behind settee backrests. Off white leather upholstery.

Navigation Station

Located on the starboard side aft of the saloon. Forward facing. Surrounded by navigation and communication electronics as well as the AC and DC electrical panels. Lockers and drawers under.

Galley

Located opposite the navigation station. "L" shaped. Top and side load Isotherm fridge inboard, top load Isotherm freezer outboard. Off white colored Corian counter tops. Double stainless steel sinks. 3 burner propane stove with oven. Sharpe Carousel microwave outboard and over the stove. Lockers under the sink and outboard. Drawers aft.

Aft head

Located aft of the navigation station. White gel coated fiberglass unit to half height. Teak cabinetry above with lockers outboard. Electric head with fresh water flush and its own holding tank. Sink with hot and cold pressure water and telephone type shower.

Aft Cabin

Located aft of the galley. "U" shaped bunk with filler to make a double. Lockers and shelving outboard. Hanging locker forward. Access to aft side of engine. Additional access to the engine behind the companionway steps located between the galley and the navigation station.

Engine and hydraulics

Volvo Penta, MD22P, diesel 57HP

Saildrive 130S (new 2019)

2 x Racor fuel filters

Access under the companionway steps as well as in the aft port cabin

3 x blade folding propeller

2 x blade folding race propeller

Plumbing and ventilation

Ventilation

5 deck hatches, 1 over each cabin and each head

Night screen and bug screen on the larger deck hatches

Opening ports in the deck combing aft as well as the bulkhead either side of the companionway

Fans in each cabin

Dorade vent forward with 2 cowls

Marine Air air-conitioning with 16,000btu

Espar/Eberspacher diesel, forced air heating

Plumbing

Spectra water maker

Hot and cold pressure water in each head and at the galley

Hot and cold fresh water shower located at the swim platform

6 gallon Isotemp water heater

Foot pumps for fresh and sea water at the galley

Electrical

110volt AC shore power system

12volt DC system

2 x shore power cords with 30amp and 50 amp connections

Silent X wind generator with professionally crafted SS bracket above the radar with SS struts for radar mast down low (all components easily removed)

Magnum 2000 inverter (2016)

Battery monitors and regulators for 3 step battery charging and protection for electronics and computer due from electric winch surge

110volt interior outlets with GFIs in the heads

Reading lights

Cockpit lighting

Courtesy floor lights

Grounded chain-plates

Batteries

6 x 4PZV 440 Hawker house batteries in dining table base

1 x Group 31 electronics battery under navigation station seat (new 2020)

1 x Group 27 engine start battery under port settee

Electronics

Most of the electronics package was new in 2015. More details of the electronics package will be provided upon request.

Sailing instruments

B&G H5000 Hercules level processor

4 x H5000 GFD 5" color displays, 1 at nav station, 2 in sea hood, 1 at helm

4 x 20/20 large format displays on mast in an alloy bracket

Airmar analog boatspeed sensor

Airmar analog depth/temperature sensor

B&G 213 wand at mast head

Plotters

2 x B&G, Zeus2, 12" color MFDs, 1 at nav station, 1 at helm station

US coastal cartography

Navionics Gold series 2D charts MSD cards, US coast, Caribbean, South America and Bemuda

Autopilot may be enabled from the MFDs

B&G ZG100 GPS sensor w/integral compass

Radar

B&G 4G radar w/radome mounted on radar post aft

Radar available to both Zeus2 screens

Autopilot

Simrad AP28 autopilot

Control head in cockpit near helm

Hynautic HLDX linear drive

VHF

B&G V50 marine VHF with integral AIS receiver

H50 wireless remote handset with 2 charging cradles, 1 at nav station and 1 at helm station

Antenna mounted on top of mast

Ais

Navico NAIS400 AIS transponder with Navico NSPL400 splitter

Shares VHF antenna

Dedicated GPS antenna

Wifi

Navico/B&G WiFi system via GoFree app

PDQ Connect 7010A Kit for WiFi booster

Mob

MOB button is installed at helm station and is linked to the plotters

Satellite Communications

Iridium GO unit at nav station with remote feature

Emergency Power Pack

Weego Boost 18000mah Lithium Ion battery pack to run USB and 12volt devices

USB charger outlets at nav station and aft cabin

rig

Carbon fiber, tall rig Offshore Spars mast, triple spreader, painted 2015

Antal mainsail luff cars

Mast jack

Aluminum boom (2015)

Harken roller furler

Inner forstay for storm jib

Navtec hydraulic boom vang and backstay

Carbon spinnaker pole stowed on deck

Adjustable whisker pole

Aluminum bow sprit for Asymetric spinnakers fits to stem head fitting

All running rigging leads aft to cockpit

Running rigging all new 2015

Sails

All North Sails

Mainsail, 3Di w/2 reefs, full batten

Genoa, 3Di, 155%, light/medium

Genoa, 3Di, 140%, w/UV strip for roller furling

Jib, 3DL, 110%, cruising headsail w/UV strip for roller furling

Jib, 3Di, #3

Jib, 3DL, #4, carbon/Kevlar

Jib Top, 3DL, #1, Aramid

Spinnaker, Code 2A, Airx 700

Spinnaker, 2S AP

Spinnaker, Code 3A, reacher

Spinnaker, 1A

Staysail

Trysail

Equipment

Plow anchor

Anchor chain

Anchor rode

Fenders

Docklines

Boat hook

Mooring cleat covers for racing

EPIRB SOS406

Ship's manuals and papers

Winslow 6 x man life raft expired (new 2015)

Cockpit awning

Wind scoop

Second alum anchor with 200 feet chain and rode

Spare electric bulge pump and switch

Spare rudder bearing (metal housing and upper and lower bearings)

Extra 2 blade prop with all hardware

Spare new-unused dodger (beige)

disclaimer

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
