TRAILBLAZER

Hull

Cored fiberglass/vinylester hull topsides and solid fiberglass bottom.

Hull topsides painted blue Awlgrip (2006).

Structural bulkheads are marine grade ply wood.

Fin keel with "L" bulb.

There is the ability to add or remove up to 400kgs of ballast in the bulb as desired.

Spade rudder with carbon stock.

Aluminum quadrant with Vectran steering cables.

Single gold sheer line stripe.

Double white waterline stripe.

Open transom.

Weed cutter top leading edge of rudder.

Deck

Spring prepreg fiberglass decks with closed cell foam core.

Teak overlay on side decks and in cockpit (new about 2015).

Stainless steel stem head fitting.

Stainless steel bow rail.

Stainless steel stern rail.

1 x 19 stainless steel double lifelines.

Lifeline gate to starboard.

Anchor locker forward with deck access.

3 x opening deck hatches over forward cabin, forward head and saloon.

2 x pair fixed ports.

6 x opening ports, 4 in the coachroof and 2 in the cockpit.

Companionway with drop down self stowing board.

Stainless steel hand rails on coach roof.

1 x pair jib tracks with line car pullers.

All lines from the mast run under deck to 2 x 4 gang line stoppers, 1 each side of companionway.

Cockpit locker starboard side seat.

Lazarette locker with access through cockpit floor aft.

Mainsheet track in cockpit floor with traveler control lines exiting at pedestal.

Single carbon wheel on pedestal.

Ocean 1 gypsy 12volt anchor windlass (not installed).

Various Wichard “D” hook padeyes located on deck.

Carbon radar antenna post aft with quick disconnect wiring.

Removable helm seat/locker aft.

Winches

All Harken

2 x B560 TCR primary.

2 x B480 TCR halyard.

2 x B56 3 speed, STR mainsheet.

General Arrangement

Accomodations

Sleeps 8. 2 in each of the 2 sleeping cabins, 2 on the single settees and 2 in the pilot bunks outboard of the settees. Hand rubbed, varnished teak interior. Teak and holly cabin sole. Vinyl overhead panels. 2 heads.

Forward Cabin

“V” berth in the bow. Single seat aft to starboard. Overhead lockers the length of each bunk, port and starboard. Hanging locker aft to starboard. Door closes off cabin making cabin en-suite with the head to port.

Forward Head

Located on the port side and aft of the “V” berth. White gel coated fiberglass unit to half height. Teak above. Jabsco electric head with holding tank. Sink with hot and cold pressure water. Telephone type shower.  Lockers outboard as well as under sink. Mirror forward and on upper locker doors. Cup holders Soap dish holder. Teak shower grate. Sump pump for shower tray. Exhaust fan.

Main Saloon

Located aft of the forward cabin. Table on centerline with leaves port and starboard. Batteries are stored in the center of the table. Single settee to port and starboard with lifting backrest each side to form a pilot bunk. Ultra leather tan upholstery, new in 2010. Lockers and shelving port and starboard behind each settee. The mast steps immediately forward of the table.

Navigation Station

Located aft of the saloon on the starboard side. Forward facing. Lifting desk lid for paper chart storage. Extra cabinetry to house the GPS unit. Drawers forward. Wet hanging locker aft. Surrounded by navigation and communication electronics as well as electrical panel.

Galley

Located on the port side aft of the saloon. “L” shaped. Double stainless steel sink close to centerline. Force 10, 3 burner propane stove with oven outboard. Top loading freezer forward. Side loading fridge aft. Refrigeration driven by 12volt DC. Lockers outboard as well as under the sinks. 2 foot pedals, 1 for sea water.

Aft Cabin

Located aft of the galley on the port side. Double “V” type berth. Lockers and hanging locker forward and outboard. Access to back end of engine under furniture in board.

Aft Head

Located aft of the navigation station and on the starboard side. White gel coated fiberglass unit to full height. Teak above. Jabsco manual head. Sink with hot and cold pressure water. Telephone type shower.  Lockers outboard as well as under sink. Mirror on upper locker doors. Cup holders Soap dish holder. Teak shower grate. Sump pump for shower tray. Exhaust fan.

Engine

Engine access is under the companionway steps.

Volvo Penta, D2-55, 53HP diesel engine with saildrive transmission.

2 blade folding propeller.

Plumbing and Ventilation

Composite sea cocks for all through hull fittings below waterline.

Drinking water purifier.

Hot and cold water deck shower in cockpit.

Foot pump for sea water in galley.

“Y” valve for forward head.

2 x manual bilge pumps.

1 x electric bilge pump.

Tank gauges for water and fuel.

Exhaust fans in galley and heads.

Engine space air intake and fan exhaust.

Remote control fire extinguisher in engine space.

Electrical

290Ah house battery bank located in vented box in dining table.

12volt 46Ah starting battery in same box.

115volt AC shore power with plug in cockpit.

12volt DC system.

Mass 12/80 battery charger.

Mass 12/1200 Sine inverter with Masterlink MICC panel.

Mast base and shrouds grounded to keel.

12volt outlets at navigation station.

Main electrical switch panel at navigation station.

130Amp alternator with 3 step regulator for house batteries.

60Amp alternator for engine start battery.

Electronics

At Nav Station:

Northstar 951X GPS in its own cabinet.

Big Bay screen displaying software off the main computer.

B&G Hercules 2000 wind/speed/depth MFD

ICOM IC-M502 VHF.

ICOM SP-24 speaker.

ICOM IC-M802 SSB.

Raytheon RL 70C Pathfinder plus radar.

At helm:

B&G Hydra autopilot with hydraulic ram.

Radar antenna post.

Suunto compass on pedestal.

Rigging

Carbon fiber 15/16ths mast.

Double swept back carbon spreaders.

Carbon fiber boom.

Single line reefing for 2 reefs.

Double ended main sheet.

Main chain plates all the way outboard.

Navtec stainless steel rod rigging.

Carbon instrument bracket under goose neck.

Mast and boom clear coated (2010).

Additional forestay with Tuff Luff for racing.

Carbon spinnaker pole with track on mast.

Spare spinnaker pole.

Carbon fiber bow sprit for asymmetric sails.

Reaching strut.

Harken roller furler for headsail.

Navtec hydraulic panel, 1 each side.

Hydraulics for backstay and mainsail outhaul.

Adjustable mast base.

Hydraulic jack for mast base to adjust rig tension.

Quick release for hydraulic backstay.

Sails

North 3DL mainsail.

North MN mainsail (2008).

UK Dacron mainsail.

UK storm trisail.

Doyle Stratis jib.

North light jib (2007).

North 3DL Medium jib (2005).

North M3 3DL jib.

North #3 jib (2006).

UK storm jib.

UK #3 jib.

UK jib top.

North code 1A (2005).

North code 2S 0.5oz spinnaker (2009).

North code 2A spinnaker (2005).

Doyle A2 spinnaker.

UK A3 spinnaker.

Doyle A3 spinnaker with sock.

UK light asymmetric 4 spinnaker.

UK S4 heavy.

Code zero.

Doyle spinnaker staysail.

Spinnaker sock with snuffer.

Additional Equipment

Cockpit table including padded storage bag.

Cockpit dodger.

Mosquito screen drop board for companionway.

Aluminum bar in anchor locker and cockpit locker to stow running rigging.

12 x man life raft.

Gale rider.

Safety equipment for Cat 1 offshore racing.

Nautor, ships manuals.

Trailer for hauling yacht’s gear.

Light weight emergency tiller.
