KATFACE

Upgrades

2022

4 x 6V Rolls batteries in series to give 24V 440 Ah house bank

2021/22

Jib and spinnaker halyards replaced

2021

2 x 12V marine batteries in parallel for 12V engine bank

Alpine CDE 2038 bluetooth stereo with speakers in forepeak, salon, aft cabin, and cockpit (2021)

2019

Airmar DST800 depth/speed/temperature sensor

2018

Main halyard replaced and topping lift added

Hull stripped down to fiberglass and put through complete osmosis treatment with hot vacuum system

2017

JEFA DU-WS300-24 300NM Sprocket Drive in steering pedestal. (“Big Auto”)

B&G AC12 Autopilot computer under aft bunk

B&G RC42 rate compass

B&G RF300 rudder sensor

B&G WR10 Wireless autopilot controller and bluetooth base station

Note: Older B&G network pilot and autohelm drive retained as spares. Required wiring in place. Network pilot display retained in cockpit.

Schenker Smart 30 lit basic watermaker installed

Charles isolation transformer. Configurable to accept 240V European power and output 120V.

2014

Stainless steel Navtec rod rigging

Reckmann roller furler refurbished

B&G Zeus Touch 7 chart plotter

B&G External GPS antenna

2 B&G IS40 displays in cockpit

B&G NAIS-400 Class B AIS Transceiver inside helm station

B&G NSPL-400 AIS/VHF antenna splitter inside helm station

B&G wind sensor and extended NEMA cable

B&G WIFI-1 Go-Free WiFi transmitter inside helm station

Redundant battery to battery 24V to 12V chargers. Sterling power BB24 and Victron Orion Smart 20A bluetooth. Selectable by switches mounted in engine compartment

2013

Yanmar 4JH-5E

Quick 10 liter 120V water heater

Hull

Hull stripped down to fiberglass and put through complete osmosis treatment with hot vacuum system. (2018)

Self polishing paint used exclusively

Solid fiberglass hull with original white gel coat

Single Nautor blue waterline stripe

Single Nautor blue sheer stripe

Trapazoidal fin keel

Spade rudder

Boarding ladder

Deck

Cored fiberglass deck with teak overlay

Double cockpit arrangement

Companionways in the forward and aft cockpits

Stainless steel stem head fitting w/single Delrin anchor roller

Stainless steel bow and stern rails

Stainless steel stanchions with double 1 x 19 stainless steel wire lifelines

Lifelines gates port and starboard

Recessed deck light at bow to illuminate the headsail luff

Aluminum anodized toe rail

Two deck fitting fwd to receive stand up blocks for pole downhaul

2 x stand up guy blocks, 1 on each side deck

Lofrans electric anchor windlass w/chain gypsy and rode winch

Up and down deck foot switches for windlass

Anchor locker hatch

2 x pair mooring cleats, 1 fwd and 1 aft

3 x pair mooring line chocks, 1 fwd, 1 midship, 1 aft

Stainless steel crash bar around base of mast

Nautor turning blocks at the mast partners

2 x pair of genoa tracks each w/Lewmar cars

Mainsheet traveler track w/control lines

5 x deck light prisms

2 double headsail sheet lead blocks aft, 1 each side

2 x pair spinnaker sheet turning blocks aft toe rail

Edson outboard bracket on aft rail

Dodger over fwd companionway

Dodger over fwd end of aft cockpit

Stainless steel removable boom gallows

Solid removable bimini

Outboard engine davit

5 x pair Wichard "D" hooks

Pedestal steering with stainless steel wheel and elkhide cover

Double Nautor line stopper P

Single Nautor line stopper S

Winches

All Lewmar, self tailing and chrome plated

1 x #16, outhaul on boom

4 x #52, halyard on coachroof

4 x #46, utility on coachroof

2 x #65, primary at mid cockpit

2 x #46, mainsheet either side of aft companionway

2 x #58, electric secondaries either side of aft cockpit

General arrangment

Accommodations

Burmese teak interior furniture with varnished hand rubbed satin finish except as noted below. Teak and holly cabin sole. Sleeps a total of 7. 2 in each of the 2 sleeping cabins and an additioal 3 in the main saloon. 2 heads. Lee cloths on all bunks.

Forward Cabin

Offset double bunk to port with custom mattress. Locker access fwd. Shelves P and S. 2 x fans. 2 x reading lights. Seat to S. Hanging locker and shelves aft.

Forward head

Located P side aft of forward cabin. White gel coat fiberglass pan to half height. Baby Blake head, recoated. Mansfield holding tank. Pressure hot and cold water. Telephone type shower. Lockers outboard. Mirroe fwd. Teak showe grate.

Saloon

"U" shaped settee to P w/pilot berth outboard. Straight settee to S with shelving and lockers outboard. Tan leather upholstery. Table on the centerline w/leaves P and S.

Navigation Station

Located aft of the saloon and on the S side. Forward facing. Surrounded with navigation, communication and electrical instruments and panels. Fan. Drawers fwd.

Galley

Located opposite the navigation station and on the P side in the walkway to the aft cabin. Top load freezer w/twin wire baskets. Side load fridge. Refrigeration system is 24 volt, battery powered, Frigaboat, new in 2009. Force 10, 3 x burner propane stove w/oven new in 2006. Extractor fan over stove. Double stainless steel sinks inboard. Hot and cold pressure water. Water tank vents at sinks. Lockers outboard. Drawers. Trash bin. Extra fold up counter top space. 2 x foot pump pedal, 1 for sea water. Soap dispenser.

Aft Cabin

Full width cabin using the bridge deck between the cockpits for headroom. Centerline double bed w/custom mattress. Removable stairs to aft companionway store under the bunk. reading lights. Mirror fwd. 2 x fans. Hanging locker fwd P and S.

Aft Head

As described in FORWARD HEAD.

Engine

Yanmar 4JH-5E (new 2013)

1500 hours on engine as of April 2022

Morse engine control lever at helm station

Engine switches and dials at helm station

3 x blade PYI feathering propeller

Plumbing and Ventilation

Water capacity 100 gallons (tank 1 removed to fit watermaker. May be refitted)

Pressure hot and cold fresh water

Quick 10 liter 120V water heater, (2013)

Schenker Smart 30 lit basic watermaker installed in 2017

Water tank guage

110 volt and engine take off Haato water heater

Sea water deck wash at bow

Hot and cold fresh water shower on deck aft

Whale manual gusher pump P side in aft cockpit

Electric bilge pump

Electric and manual shower sump pumps

Baby Blake heads powder coated 2011

1 x large sliding hatch on foredeck w/Plexiglass replaced 2010

5 x additional opening deck hatches w/Plexiglass replaced 2010

10 x opening ports w/screens and Plexiglass replaced 2010

Dorade vent fwd of mast w/cowl and mushroom vent

2 x dorade boxes, 1 each side of fwd companionway

Dorade box aft w/2 x cowls

2 x mushroom deck vents, 1 at galley, 1 at nav station

Electrical

AC power:

Wired for 120V 60Hz AC

Charles isolation transformer, installed 2017. Configurable to accept 240V European power and output 120V

Victron Phoenix V.E. DirectSmart 1200W/230V inverter to supply 2 British type 230V outlets

DC power:

4 x 6V Rolls batteries in series to give 24V 440 Ah house bank (2022)

Heart 2500 inverter/charger with Link 2000 smart battery monitor

Victron SmartBVM 712 bluetooth battery monitor for house bank

Solar Panels with Victron 100/15 SmartSolar MPPT controller

Balmar 60-24-70 Alternator with MC-624 Voltage Regulator

2 x 12V marine batteries in parallel for 12V engine bank (2021)

Redundant battery to battery 24V to 12V chargers. Sterling power BB24 (2014) and Victron Orion Smart 20A bluetooth. Selectable by switches mounted in engine compartment.

Fisher Panda 5KW gen set, new 2007, located under bunk in fwd cabin

110 volt and 24 volt electrical panel at navigation station

1 x 30 amp 110 volt deck plug

1 x TV and cable deck plug

2 x 175 watt, 24 volt Solar panels over hard bimini

24 volt outlet in aft cockpit

110 volt outlets below deck

Inverter/battery charger w/Heart Interface Link 2000 system

Electrical switch panel at helm station

Tri color mast head light

Electronics

The following were installed in 2014:

B&G Zeus Touch 7 chart plotter

B&G External GPS antenna

2 B&G IS40 displays in cockpit.

B&G NAIS-400 Class B AIS Transceiver inside helm station.

B&G NSPL-400 AIS/VHF antenna splitter inside helm station.

Airmar DST800 depth/speed/temperature sensor. (Replaced 2019).

B&G wind sensor and extended NEMA cable.

B&G WIFI-1 Go-Free WiFi transmitter inside helm station.

The following were installed in 2017:

JEFA DU-WS300-24 300NM Sprocket Drive in steering pedestal. (“Big Auto”)

B&G AC12 Autopilot computer under aft bunk.

B&G RC42 rate compass.

B&G RF300 rudder sensor.

B&G WR10 Wireless autopilot controller and bluetooth base station.

Note: Older B&G network pilot and autohelm drive retained as spares. Required wiring in place. Network pilot display retained in cockpit.

Rigging and Sails

Nautor built aluminum anodized mast w/double spreaders

Stainless steel Navtec rod rigging (new 2014)

Antal batt car system

Deck lights under lower spreaders

Nautor built aluminum anodized boom

Carbon Hall spars spinnaker boom stored on deck (P)

Nautor built aluminum anodized strut stored on deck (S)

Main halyard replaced and topping lift added 2018

Jib and spinnaker halyards replaced 2021 and 2022

Reckmann roller furler refurbished 2014

Lazy jacks for mainsail

2 x spinnaker halyards

2 x headsail halyards

1 x staysail halyard

Inner forestay, removable to a padeye on the coachroof aft of the mast

Baby stay

Navtec hydraulic panel in aft cockpit

Hydraulic backstay, babystay, inner forestay and boom vang

Halyards and sheets, new 2010

Sails

Mainsail, Doyle, full batten, new 2011

130%, Doyle genoa

Staysail with hanks attaches to inner forestay

100%+- jib

Mainsail, North, full batten

Asymmetric spinnaker with sock, North

0.5 oz symmetrical spinnaker

Additional Equipment

Espar diesel forced air heating system

Sea-Safe PL-SR6 6 person life raft. Next inspection due 2023 in hard cannister in stainless steel cradle on coachroof top

Spade anchor

300 feet anchor chain

Danforth anchor

Fortress anchor for spare and used as strong stern anchor

Flagstaff

Horseshoe life-ring

Windex on mast head

Load hailer

Alpine CDE 2038 bluetooth stereo with speakers in forepeak, salon, aft cabin, and cockpit (2021)

Chelsea clock and barometer

Cockpit cushions, new 2010

Sunbrella delivery covers

Sunbrella winch covers

Teak cockpit table

8 x Hella fans throughout interior, new 2011

Spares and rebuild kits
