MENSAE

NEW TEAK DECKS 2018! In the winter of 2017/18 MENSAE benefitted from a partial refit. This refit included new teak decks, new deck hatches, new Windlass, new AIS, new antennas, new bottom paint, fresh varnish in parts of the interior, servicing of many of the hydraulic, electrical and plumbing systems.

HULL

Solid fiberglass hull using optional Vinylester resin.
White Awlgrip painted hull (2011)
Blue sheer and boot stripes.
Fin keel with 8'4" draft.
Spade rudder.
Hydraulic fold down transom to form a swim platform.
Optional deep draft keel also available for racing.
Window in hull to inspect the propeller.

DECK

Cored fiberglass decks with teak overlay. Teak replaced winter 2017/18.
Oversized teak toe rail.
Stainless steel stem head fitting.
Lewmar Ocean 2 anchor windlass under deck. (new 2017)
Stainless steel bow and stern rails.
Stainless steel stanchions.
1 x 19 stainless steel double life lines.
Folding midship docking cleats.
Stainless steel roller fairleads for mooring lines.
Storage lockers in cockpit.
Teak foot blocks for helmsman.
Stainless steel bracket over pedestal instruments.
1 x pair genoa tracks with car pullers.
Line stoppers.
Harken deck hardware.
Wichard padeyes for safety lines and alternative sheeting angles.
White painted aluminum radar and antenna post aft.
Stainless steel handrail at companionway.
Gangway fitting at stern.
Cockpit table with fitted canvas bag.

WINCHES

All Lewmar and self tailing.
2 x #77, 3 speed, primary operated with a pedestal.
2 x #65, 2 speed, secondary, electric for trimming cruising headsail.
2 x #54, 2 speed, mainsheet.
2 x #64, 2 speed, secondaries.
4 x #44, 2 speed, halyard and utility.
2 x #44, 2 speed, main traveler.

GENERAL ARRANGEMENT

ACCOMMODATIONS

See the drawing below.

Sleeps 6, 2 in each of the 3 sleeping cabins, plus 1 in the forepeak cabin and 4 in the main saloon for a total of 11. Varnished, hand rubbed, golden Burmese teak veneer over marine ply over the majority of the furniture. Teak and holly cabin sole and vinyl overhead panels.

FOREPEAK

Located in the bow. Ample storage with fold down pipe bunk on the starboard side. Work bench. Stainless steel bars to store running rigging.

FORWARD GUEST CABINS

Mirror image guest cabins forward of the main bulkhead with 2 single over and under bunks in each cabin. There is a shared head forward and to starboard with teak shower grate.

MAIN SALOON

"L" shaped settee to starboard surround an offset dining table. Upholstery in the main saloon and navigation station is leather. There are two additional single chairs inboard. There is an arrangement to allow for a pipe bunk over the port and starboard settees. Out board of the settee is storage lockers and a shelf. On the port side is a straight settee, also with storage lockers outboard with roller doors.

NAVIGATION STATION

Located aft of the saloon and on the starboard side. Forward facing and surrounded with navigation and communication electronics.

GALLEY

Located opposite the navigation station and on the port side in the walkway into the aft cabin. Corian counter tops. Corian and teak sink covers for more surface space. Side load fridge and top load freezer are forward driven by engine or 110volt followed by the Force 10, 4 burner stove with oven and storage aft. Microwave oven. Inboard are the stainless steel double sinks with storage above. Access door aft to the engine space. Access to the engine space may also be gained under the companionway steps.

MASTER CABIN

Located in the aft end of the yacht and accessed via the galley. Queen sized double bed on the centerline with a vanity to starboard and a seat to port. Ample storage lockers and hanging lockers in the cabin. Ensuite head on the starboard side forward of the cabin may be accessed from the master cabin as well as the navigation station allowing it to be used as a convenient day head. Full length mirror.

ENGINE

Yanmar 4JH-UTBE 96HP diesel engine.
3 x blade Max Prop.
2 x blade folding propeller as spare for racing.

PLUMBING and VENTILATION

PLUMBING

Seafresh H2O6A watermaker, 2200 liters per day.
Hot and cold water deck shower at transom.
Fresh water and sea water connection at forward deck.
Vacuflush heads with fresh water flush.
Black water holding tank for aft head.
Water heater off engine and 110volt.
Electric bilge pump with manual and automatic control.
Electric shower sump pumps.
2 x fresh water pressure pumps.

VENTILATION

Reverse cycle air conditioning in main saloon.
5 x turbo cabin fans.
Dorade vents with stainless steel protection bars.

ELECTRICAL

Westerbeke 8KW generator with silent exhaust.
Mass Inverter 24/1500W, 115volt.
Mastervolt battery charger (2012).
115volt and 220volt deck plug with 3Kva transformer.
115volt outlets through the interior.
Shore power cord.
24volt DC system.
House battery bank (2014) with DDC 4000 battery capacity meter.
Engine battery (2014).
Generator battery (2014).
Dimmer for cabin lights.
Tricolor mast head light.
Spreader lights with dimmer.
Headsail luff light with dimmer.
Steaming light on mast.

ELECTRONICS

Raymarine radar (2009).
E120 at navigation station as well as at helm.
Raymarine GPS.
Trimble GPS.
Furuno WAAS GPS.
B&G autopilot (2015) with 2 displays.
B&G Hercules instruments.
2 x B&G MFDs at navigation station.
5 x B&G MFDs in cockpit.
4 x B&G displays on mast under goose neck.
B&G Super Halcyon electronic compass.
Furuno PG 1000 compass.
Furuno weather fax, FAX207.
Icom 604 VHF at navigation station.
Icom RAM mike at helm.
Icom ICM710RT SSB.
Additional handheld VHF.
Trane and Trane Mini M Sat telephone with data/fax/PC interface.
WiFi amplifier.
GPS portable Global Star phone with mounted docking station.
Cojot antenna at mast head.
Apple computer aft cabin for media and DVD viewing.
HP computer for navigation with Nobeltec and Oceans Nav and weather software.
Flatscreen TV.
Sony radio/CD in owner's cabin.
Denon DVD player with surround sound.
Cockpit speakers.

RIGGING and SAILS

Nautor aluminum, white painted mast.
Separate trysail track on mast.
2 x folding mast steps.
Nautor aluminum, white painted boom.
Navtec stainless steel rod rigging.
Aramid checkstays.
Carbon fiber spinnaker pole.
Aluminum jockey pole.
Navtec hydraulic vang, backstay, babystay and mainsail outhaul.
Electric roller furling headsail.

SAILS

Dacron full batten mainsail w/2 reefs (2015).
Dacron roller furling genoa (2015).
Dacron staysail (2004).
Dacron storm jib (2004).
Dacron storm trysail (2004).
0.5oz spinnaker (2000).
Cruising spinnaker with sock (2004)

EQUIPMENT

AB hard bottom inflatable dinghy (2009).
15HP outboard engine (2009).
Winslow 6 man life raft.
MOM.
EPIRB
Bosun's chair.
6 x lifejackets.
5 x fenders.
Fender board.
Slip covers for upholstery.
Padded cover for dining table.
Stainless steel spade anchor.
200ft 9/16 anchor chain.
Winch handles.
Snatch blocks.
Outboard bracket on stern rail.
Dodger for companionway.
Dodger for aft cockpit.
Bimini.
Full awning.
Cockpit cushions.
Wheel cover.
Lee cloths for bunks.
Flagpole and ensign.
