Swan 77 sold by Yeoman Yachts:

AQUILA

Yeoman Yachts, once again, is proud to be appointed the Central Agent for the 2002, Swan 77, AQUILA.

AQUILA, previously named CYGNUS MONTANUS II, has been owned by the present owner for close to four years. In that time AQUILA has sailed between the Caribbean and New England following the seasons. AQUILA has also been a successful charter yacht, in the US as well as the Caribbean, when the owner has elected not to be aboard.

Recent upgrades include new North Sails main and genoa, standing rigging, generator, refrigeration, batteries and some electronics.

AQUILA was originally built with shallower than standard draft to allow access to more cruising grounds around the world and an extended transom to provide even more storage space in the lazarette.

Attractively priced, offers encouraged.

  • Year:

    2002
  • Model:

    Swan 77
  • Location:

    Bridgeport - Connecticut - USA

Sold - Swan 77 AQUILA

  • Model:
    2002 Swan 77
  • Hull Number:
    77.008
  • LOA:
    77 ft 0 in
  • Beam:
    19 ft 7 in
  • Draft:
    9 ft 8 in
  • Displacement:
    112400 lb
  • Keel:
    Fin
  • Engine:
    Perkins Sabre M225Ti

Hull

Single skin glass/aramid hybrid laminated hull construction

Topsides finished in Awlgrip Flag Blue paint (2002)

Boot stripes and cove stripe finished in Awlgrip (white and gold)

Coaming and cabin top finished in NGA 2000 white gelcoat

Interlux Micron extra bottom paint dark blue

Reduced draft keel designed by German Frers, 2.98m rather than standard 3.4m

Hydraulically operated swim platform in transom with stairs and swim ladder

Extended transom with 2 large hatches to access aft lazarette

Tinted Perspex hull windows in main saloon flush with hull on outside

MaxPower retractable bow thruster (new 2021)

Steering System 1.8 meter (70 inch) diameter wheel with elk-hide cover

Rudder of foam filled fiberglass with high tensile stainless-steel stock

Rudder depth reduced by 20 cm to account for shallow draft keel

Deck

Construction

Fiberglass sandwich construction with foam core

Teak on side decks, coach roof, bridge deck, cockpits, coamings, and both sides of companionway

Varnish teak toe rail

Ventilated gas locker in aft cockpit

Deck Equipment

Stem head fitting with double rollers and chain locating roller on starboard side

Bowsprit for gennaker designed to fit port stem head slot (Nautor)

Stainless-steel bow pulpit with teak seat and gate

Stainless-steel stern pushpit with gate

Stainless-steel stanchions with gates port and starboard

Painted radar post aft with radar, VHF antenna, Iridium antenna, Inmarsat antenna, lights fore & aft

Fixed mooring cleats x 6 (2 fwd, 2 midship, 2 aft)

Closed roller fairleads aft and midships, open roller fairleads fwd

Folding leaf table in forward cockpit with leaves folding upwards for more leg space

Custom steering pedestal with Simrad NSE 8 Plotter/Radar, B&G FFD and pilot control

Hydraulics

Bosch Rexroth 11 Function hydraulic system with PTO pump back-up

2 x primary winches

2 x secondary winches

2 x halyard winches

1 x mainsheet winch

1 x windlass

1 x Reckmann headsail roller furler

1 x Leisurefurl in boom furling system with Rondal Captive main halyard winch

1 x Maxpower bow thruster

Winches

AQUILA has an upgraded Lewmar winch package delivered from Nautor including:

2 x Lewmar 111 hydraulic 3 speed SS primary winches placed further aft than standard

2 x Lewmar 77 hydraulic 3 speed chrome secondary winches positioned on aft coaming

1 x Lewmar 66 hydraulic 3 speed chrome mainsheet winch

1 x Lewmar 48 1 speed chrome traveler control winch

2 x Lewmar 66 hydraulic 2 speed chrome genoa halyard winches

2 x Lewmar 66 2 speed chrome spinnaker halyard winches

1 x Rondal 4000/550 hydraulic captive main halyard winch

1 x Lewmar 3000 vertical reversing hydraulic windlass

Sailing Hardware

All deck equipment by Lewmar, Harken, Spinlock or Nautor

Harken stainless-steel recessed genoa and staysail sheet tracks

Harken alloy mainsheet track with roller bearing cars

Harken screw in fittings for gennaker blocks

Spinlock jammers at mast base for line organization

General Arrangement

Accommodations

Sleeps 9 in 4 separate guest cabins plus 3 in the crew cabin for a total of 12. All interior joinery is Burmese, varnished, hand-rubbed teak with a satin finish. Saloon, galley and navigation station area lockers and drawers made with highlight paneled doors. Teak and holly cabin sole. White vinyl over paneling headliner.

Forward Cabin (crew quarters)

Generous crew space finished with the same high level of decor as the remainder of the yacht. Fixed berth to starboard with storage underneath. Pullman bunk to port with settee underneath which converts to third bunk. Chain locker access under hanging locker. Storage lockers outboard of pullman berth. Ensuite head with shower, sink, mirrors, storage lockers and manual toilet. Bosch washer and Miele dryer. Automatic lights in lockers. MarineAir Air Conditioning.

Port Guest Cabin

Large and comfortable VIP guest cabin with ensuite head and shower. Located aft of the forward cabin. Double berth with drawers below. Folding pullman berth above. Hanging locker on centerline bulkhead with drawers below. Vanity with countertop and storage below. Automatic lights in lockers. Storage lockers outboard of pullman berth. Ensuite head with shower, sink, mirror, storage lockers and VacuFlush toilet. MarineAir air conditioning.

Starboard Guest Cabin

Great for the children or the grandchildren. Located aft of the forward cabin. Single berth with drawers below. Folding pullman berth above. Hanging locker at aft bulkhead with drawers below. Storage lockers outboard of pullman berth. Ensuite head with shower, sink, mirror, storage lockers and VacuFlush toilet. Automatic lights in lockers. MarineAir air conditioning.

Main Saloon

Masses amounts of space with 2 totally separate seating areas. Cozy and inviting. U shaped settee to port with storage lockers outboard fore and aft of hull windows. Coffee table to port with flat screen Sharp TV that rises out of table. U shaped settee to starboard with storage lockers outboard fore and aft of hull windows. Dining table to starboard seating 8 people. Custom bar area at forward bulkhead with bar, crystal storage, drinks fridge and ice maker. Raised ceiling with indirect lighting. Automatic lights in lockers. MarineAir air conditioning x 2.

Galley

Any professional chef would be thrilled to work in this galley. Lots of counter space, lockers and drawers with all the modern conveniences to prepare the best of dishes. The open galley is located aft of the saloon on the port side. All work surfaces in galley and sliding doors behind stove in Corian. Magna Sahara gimbaled 4 burner Force 10 stove and oven. Miele 2 burner induction hob. Miele microwave oven. Overhead Alpes Inox extractor fan with lighting. Double stainless-steel sinks inboard. Miele dishwasher. Insinkerator brand garbage macerator in sink. Refrigeration: Front loading refrigerators x 2. Top loading freezer. Freezer under galley floor. Drinks fridge in saloon custom bar.

Navigation Station

Oversize desk to allow the opening of paper charts if needed. Strategically located to maximize on-deck and below communications. Open navigation station located aft of saloon on the starboard side. Forward facing double navigation seat. Lockers, drawers and in-desk storage. Chart storage in overhead chart locker.

Captain’s Cabin

Great, cozy off watch cabin located where the least amount of boat motion occurs. Located aft of the navigation station and to starboard side of engine room. Fixed upper and lower berths with drawers below. Hanging locker aft with drawers below. Air conditioning drawn from owner’s cabin. Automatic lights in lockers. Ensuite head (doubles as day head) with shower, sink, mirror, storage and VacuFlush toilet.

Hallway

Accesses the owner's cabin aft creating lots of privacy from the remainder of the yacht. Located on the starboard side. Electrical panel. Door to access engine room. Hanging locker aft, vented with drain in floor and storage shelves for safety equipment.

Owner's Cabin

Palatial! Lots of privacy, large comfortable bed, ensuite head and stall shower. It is hard to imagine a better-appointed cabin for the owners. Located aft. Centerline queen sized berth with drawers below. Settee to port. Hanging lockers port and starboard with drawers below. Large vanity mirror with lighting and shelf with storage below. Work desk to starboard. Ensuite head with stall shower, sink, mirror, storage lockers and VacuFlush toilet. Automatic lights in lockers. MarineAir air conditioning.

Engine Space

Engine room located centerline beneath forward cockpit and lined with full sound insulation. Access via door in hallway and under companionway steps. Generator space under floor in main saloon lined with full sound insulation (genset in sound box also).

Engine

Perkins Sabre M225Ti diesel engine with Max Prop. Whisper 5 Blade Feathering prop

Plumbing and Ventilation

Fresh Water System

Freshwater capacity 362 gallons in 2 stainless-steel tanks. Sea Recover Aqua Whisper 230 V watermaker making 1,500 US gallons/day, including: fresh water flush system, ultraviolet sterilizer, clean and rinse valves, commercial pre-filter, 2 x high pressure water pumps by TF Marine, 24V, 3000l/h. Low water alarm. Tank vent pipes at galley sinks. 220V water heater with 100 liter capacity. Engine heated hot water via same water heater. Hot and cold showers at swim platform and in aft cockpit.

Sea-water System

Sea-water pump distributing water to deck wash and galley.

Heads

Vacuflush vacuum toilets using freshwater for flushing x 4. Jabsco manual toilet in forward cabin using sea water for flushing. Black water stored in 2 x black water tanks, emptied by electric pumps or deck fittings. Level indicators for black water tanks in heads and at monitoring panel.

Ventilation

Natural ventilation in all cabins. Exhaust ventilators in all heads and in galley. MarineAir reverse cycle air conditioning installed in: owners cabin, saloon port, saloon starboard, port guest cabin, starboard guest cabin, forward cabin.

Drainage Systems

Galley sinks drain through seacock. Wash basins and showers drain to sump tanks (emptied by electric pumps). 2 x electric submersible bilge pumps (main bilge and bow locker). 2 x Whale Titan manual bilge pumps. Manual backup pumps for sump tanks. Manual pump for chain locker.

Refrigerator Systems

Iceberg 220V refer system for fridge and 2 freezers, sea water cooled. Iceberg engine driven refer system for fridge and 2 freezers, sea water cooled. Waeco Coolmatic drinks fridge installed in custom bar area. Raritan Icemaker installed in custom bar area.

Electrical

DC System

24V DC system insulated return system

Service battery bank 24 V 1200 Ah gel cell (new batteries 2020)

Radio battery bank 24 V 240 Ah gel cell

Engine starting bank 24 V 135 Ah gel cell

Generator starting bank 12 V 90 Ah gel cell

Mastervolt Mass 24/75 x 2 220 V

70 A battery chargers x 2 for service bank

Mastervolt Mass 24/50 220 V 50 A battery charger for radio bank

AC System

50 A 230 V 50/60 Hz single phase fed from shore power, generator or inverters

Shore power inlet for 230 V 50 A

50 Hz through a 12 kVA step up / step down isolation transformer

Shore power inlet for 115 V 50 A

60 Hz through a 6kVA transformer

Shore power inlet for 230 V 50 A

50 Hz through a 12 kVA step up / step down isolation transformer for AirCon

Mastervolt Mass Inverters, 1500 and 5000 W 230 V 50 Hz sine wave

Northern Light Generator 16 kVA 230 V 50 Hz including sound shield (new in 2019)

60 Hz protection system (protects 50 Hz only consumers when plugged into a 60 Hz power source)

Electronics

Navigation System

B&G Hercules 2000 racing package

8 x B&G FFD displays

5 x B&G 20/20 displays

2 x B&G Hercules Pilot displays

B&G Barometer sensor

B&G Heel angle sensor

B&G Gyro stabilized compass

B&G Extended Carbon Fiber MHU wand

Simrad NSE12 Chartplotter/Radar/GPS at navigation station

Simrad NS8 Chartplotter/Radar/GPS at helm

Simrad 4G radar

Simrad AIS transceiver

Computer Systems

1 x Shuttle computer with 500 GB storage, I3 processor, 8 Gigs of RAM, CD drive, multiple USB connections, wifi connection

Nobeltec TC Time Zero Charting software ver. 3.0 with all US Raster/Vector charts included

Map Media charts for the Caribbean, Gulf of Mexico, Bahamas and Bermuda

2 x HP small frame PC's built in (one designated for communications, one designated for navigation)

HP 15 inch flat screen monitor

MaxSea interfaced with autopilot via selector switch (Simrad or MaxSea to drive B&G)

HP Deskjet printer

Communications Systems

Skanti built in Iridium satellite phone with data

Handheld Iridium satellite phone with data

Thrane and Thrane built in Inmarsat FB 250 satellite phone with data

ICOM SSB radio

ICOM VHF radio with DSC x 2

Panasonic telephone exchange

Nokia 22 GSM terminal

Entertainment Systems

Sharp Flat Panel LCD TV (rises out of coffee table)

Denon AV 1709 DVD/CD/AV system in saloon

Sony DVD/CD player in saloon. 6 speaker system in main saloon (4 Boston Acoustics speakers in ceiling, center speaker and sub-woofer)

4 cockpit speakers with controls in cockpits and at main system (2 in forward cockpit, 2 in aft cockpit)

Rigging

Spars

Offshore Spars carbon fiber mast with 4 sets of spreaders painted white

LeisureFurl, carbon fiber, hydraulic furling boom, painted white

Oversized Navtec push/pull boom vang

Navtec rod rigging (new in 2015)

Aramid runners, check stays, inner forestay and baby stay

Some running rigging replaced (2019)

Reckmann RF-90 hydraulic headsail roller furling system

Gennaker bowsprit

Rigging Hydraulics

Navtec System 50 controlling:

Back stay

Inner forestay

Baby stay

Genoa halyard

Boom up boom down

Sails

North mainsail, offshore ply with 3 reefs (new 2018)

North 3Di Endurance, offshore ply, cruising genoa (new 2018)

Quantum gennaker with snuffer (2002)

Additional Equipment

General Equipment

Bauer Junior II dive compressor, 300 BAR, mounted in aft lazarette

4 x Suunto 300 BAR DIN dive tanks

4 x Suunto 300 BAR DIN regulators

Safety Equipment

2 x Zodiac Offshore 6 person life rafts in a valise (new 2017)

2 x Survival Technologies MOM-8 man overboard modules

PUR -6 handheld watermaker

ORC Category 1 offshore flare kit

BMC Medical offshore medical pack

BMC Medical offshore grab bag

ADK Marine Medical Kit 1000

Canvas

Antigua Sails awning

Antigua Sails foredeck awning

Antigua Sails forward cockpit spray hood

Antigua Sails aft cockpit spray hood

Antigua Sails wheel cover

Antigua Sails binnacle cover

Antigua Sails spinnaker pole cover

Antigua Sails tender cover

Antigua Sails tender console cover

Antigua Sails tender engine cover

Antigua Sails air scoops

Antigua Sails hatch wedges

Table covers x 3

Cockpit cushions for forward cockpits

Cockpit cushions for mid-section (between the 2 cockpits)

Cockpit cushions for the aft cockpit and helms seat

Optional upgrades during build

The following options were made during construction at Nautor:

Shallow draft keel version

Custom steering pedestal

Hydraulically operated

Swim platform

Extended transom with 2 lazarette hatches and locker

Hull windows

Upgraded winch package

Captive winch package

Additional aft cabin porthole

Teak outboard lockers and trim in heads

Scandiflex bottoms under VIP cabin bunks

Paneled lockers and cupboards

Custom bar area

Raised ceiling in saloon area

Max power hydraulic bow thruster

Additional refrigeration compressor

Additional freezer under floor

Oversized service battery bank

60 Hz protection system

Dual built-in computer system

Carbon fiber mast and boom

LeisureFurl in boom furling

Oversized boom vang

Awlgrip paint, Flag Blue over blue gel coat

Disclaimer

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
